8.7 Command Message Description
186
Sets and queries the allowable value (lower limit) On/Off
Syntax
Command
Query
Response
:CONFigure:COMParator:LOWer
<character value 1>,<character value 2>
:CONFigure:COMParator:LOWer?
<character value 1>,<character value 2>
<character value 1> = OFF/ON
OFF : Allowable value data for normal condition (lower limit)OFF
ON : Allowable value data for normal condition (lower limit)ON
<character value 2>= OFF/ON
OFF : Allowable value for fault condition (lower limit)OFF
ON : Allowable value for fault condition (lower limit)ON
Function
Command Sets the setting of On/Off of an allowable value (lower limit).
Sets one On/Off setting of an allowable value (lower limit) each for normal and
single fault conditions.
The number of allowable values that can be set depends on grounding class,
network and leakage current mode.
For details, refer to allowable value (upper limit) settings and inquiry table.
Since On/Off setting of an allowable value (lower limit) cannot be set for items
indicated as 0 in the table, an Off setting is made.
Query Returns the setting of On/Off of an allowable value (lower limit).
Returns one On/Off setting of an allowable value (lower limit) for each normal
condition and single fault condition.
The number of allowable values that can be set depends on grounding class,
network and leakage current mode.
For details, refer to allowable value (upper limit) settings and inquiry table.
Since items indicated as "0" in the table have no settings, Off is returned.
Example
Command
:CONFigure:COMParator:LOWer ON,ON
Sets the On/Off setting of the allowable value (lower limit) for normal condition
to On and the On/Off setting of the allowable value (lower limit) for single fault
condition to On.
Query
Response
:CONFigure:COMParator:LOWer?
:CONFIGURE:COMPARATOR:LOWER ON,ON (Headers: ON)
ON,ON (Headers: OFF)l
The On/Off setting of the allowable value (lower limit) for normal condition is set
to On and the On/Off setting of the allowable value (lower limit) for single fault
condition is set to On.
Error
An execution error occurs in the following cases:
• When the measurement mode is not selected
• When a mode other than "leakage current mode" is set
• In automatic measurement (Command)
Note
Use this command after executing the :MODE command to activate the mea-
surement mode.
