8.7 Command Message Description
196
Error
Query
Response
:CONFigure:PCC:RANGe?
:CONFIGURE:PCC:RANGE HOLD1 (Headers : ON)
HOLD1 (Headers : OFF)
The current range for protective conductor ammeter is set to the 50 mA range.
Mode is set to something other than "protective conductor ammeter mode".
Note
Use this command after using the :SYSTem:MODE command to set the pro-
tective conductor ammeter mode.
Sets and queries current range (protective conductor ammeter)
Sets and queries the power supply polarity in manual measurement
Syntax
Command
Query
Response
:CONFigure:POLarity <characters>
:CONFigure:POLarity?
<characters>
<characters> = NORMal/ REVerse
NORMal : Positive phase
REVerse : Negative phase
Function
Command Sets the power supply polarity for manual measurement.
Query Returns the power supply polarity setting for manual measurement as alpha-
betic characters.
Example
Command
:CONFigure:AUTO OFF;:CONFigure:POLarity NORMal
Sets the power supply polarity to positive phase.
Query
Response
:CONFigure:AUTO OFF;:CONFigure:POLarity?
:CONFIGURE:POLARITY NORMAL (Headers : ON)
NORMAL (Headers : OFF)
The power supply polarity has been set to positive phase.
Error
An execution error occurs in the following cases:
• When the measurement method is set to "automatic measurement"
• When a mode other than "leakage current mode" is set
• When the measurement mode is set to Enclosure - Line leakage current,
Touch current Enclosure - Line or the measurement mode is not set
• When the type of equipment under test is set to "internally powered equip-
ment"
• When the auto range is set and a 0.1 Hz frequency range setting is made.
• When power on polarity switching is set and a power on check ends in an
error (NG), it is the instrument that is causing the error.
Note
Use this command after executing the :MODE command to activate the mea-
surement mode.
