8.7 Command Message Description
202
Sets and queries the measurement terminal of the Patient leakage current
(Patient
– Earth) and the total patient leakage current (Patient – Earth)
(only ST5540)
Syntax
Command
Query
Response
:CONFigure:TERMinal <characters>
:CONFigure:TERMinal?
<characters>
<characters> = T1T2/T2
T1T2:Terminal T1 and Terminal T2
T2:Terminal T2 and grounding terminal
Function
Command Sets the measurement terminal of the Patient leakage current (Patient - Earth)
and the total patient leakage current (Patient - Earth)
Query Returns the setting of the measurement terminal of the Patient leakage current
(Patient - Earth) and the total patient leakage current (Patient - Earth) in charac-
ters.
Example
Command
:CONFigure:TERMinal T1T2
Sets the measurement terminal of the Patient leakage current (Patient - Earth)
and the total patient leakage current (Patient - Earth) to T1 and T2 terminals.
Query
Response
:CONFigure:TERMinal?
:CONFIGURE:TERMINAL T1T2 (Headers: ON)
T1T2 (Headers: OFF)
Measurement terminal of the Patient leakage current (Patient - Earth) and the
total patient leakage current (Patient - Earth) are set to T1 and T2 terminals.
Error
An execution error occurs in the following cases:
• When measurement mode is other than the patient leakage current (Patient -
Earth) or the total patient leakage current (Patient - Earth)
• When a mode other than "leakage ammeter mode" is set
• The grounding class of equipment under test is set to something other than
internally powered equipment
• During automatic measurements
Note
Use this command after executing the :MODE command to activate the mea-
surement mode.
Sets and queries the target voltage
Syntax
Command
Query
Response
:CONFigure:VOLTage <characters>
:CONFigure:VOLTage?
<characters>
<characters> = ACDC/ AC/ DC/ACPEAK
ACDC : AC+DC(alternating current and direct current)
AC : Alternating current
DC : Direct current
ACPEAK : AC peak
Function
Command Sets the target voltage.
Query Returns the target voltage setting as alphabetic characters.
