10.4 Accuracy
260
*
1: Measurement (including cable capacity) between T1 and T2 in leakage current between
enclosure and enclosure mode
*
2: Including voltmeter (1 M load) at network output section Input protective fuse is short-cir-
cuited.
*
3: Network A (filter OFF), Network B1, B2 (filter OFF),Same circuit for network E
*
4: -15 dB points for network C (filter ON1, ON2 )
*
5: 0.1 Hz only at Network B2. Other Network from 15 Hz.
*
6: Impedance theoretical values do not include the network output unit voltmeter (1 M load)
B1
*
, B2
*
/
Filter ON
0.1Hz <f <10 kHz
10 kHz f
< 100 kHz
100 kHz
f 1MHz
± 4%rdg.±10dgt.
± 1.5dBrdg.±10dgt.
± 1.5dBrdg.±10dgt.
± 4%f.s.
± 1.5dBrdg.±2%f.s.
± 1.5dBrdg.±2%f.s.
––
C/Filter
OFF
0.1Hz <f <10 kHz
10 kHz f
< 100 kHz
100 kHz
f 1MHz
± 4%rdg.±10dgt.
± 1.5dBrdg.±10dgt.
± 1.5dBrdg.±10dgt.
± 4%f.s.
± 1.5dBrdg.±2%f.s.
± 1.5dBrdg.±2%f.s.
––
C/Filter
ON1
0.1Hz <f <10 kHz
10 kHz f
< 100 kHz
100 kHz
f 1MHz
± 4%rdg.±10dgt.
± 1.5dBrdg.±10dgt.
± 3.5dBrdg.±10dgt.
± 4%f.s.
± 1.5dBrdg.±2%f.s.
± 3.5dBrdg.±2%f.s.
± 4%rdg.±10dgt.
± 1.5dBrdg.±5%f.s.
± 3.5dBrdg.±15%f.s.
± 4%f.s.
± 1.5dBrdg.±5%f.s.
± 3.5dBrdg.±15%f.s.
C/Filter
ON2
0.1Hz <f <10 kHz
10 kHz f
< 100 kHz
100 kHz
f 1MHz
± 4%rdg.±10dgt.
± 1.5dBrdg.±10dgt.
± 3.5dBrdg.±10dgt.
± 4%f.s.
± 1.5dBrdg.±2%f.s.
± 3.5dBrdg.±2%f.s.
± 4%rdg.±10dgt.
± 1.5dBrdg.±5%f.s.
± 3.5dBrdg.±15%f.s.
± 4%f.s.
± 1.5dBrdg.±5%f.s.
± 3.5dBrdg.±15%f.s.
D
*6
0.1Hz <
f <10 kHz
10 kHz
f 1MHz
Theoretical
impedance value
± 2%
Including voltmeter
± 4%rdg.±6dgt.
Theoretical
impedance value
± 3%± 6

Including voltmeter
± 5%rdg.±6dgt.
Theoretical
impedance value
± 2%
Including voltmeter
± 4%rdg.±6dgt.
Theoretical
impedance value
± 3%± 6

Including voltmeter
± 5%rdg.±6dgt.
––
E
*3
0.1Hz <
f <10 kHz
10 kHz f
 100 kHz
100 kHz
f 1MHz
± 4%rdg.±10dgt. ± 4%f.s.
± 4%rdg.±10dgt.
±5%f.s.
±15%f.s.
± 4%f.s.
±5%f.s.
±15%f.s.
F
0.1Hz <f <10 kHz
10 kHz f
< 100 kHz
100 kHz
f 1MHz
± 4%rdg.±10dgt. ± 4%f.s.
± 4%rdg.±10dgt.
±5%f.s.
±15%f.s.
± 4%f.s.
±5%f.s.
±15%f.s.
G
0.1Hz <f <10 kHz
10 kHz f
< 100 kHz
100 kHz
f 1MHz
± 4%rdg.±10dgt.
± 1.5dBrdg.±10dgt.
± 1.5dBrdg.±10dgt.
± 4%f.s.
± 1.5dBrdg.±2%f.s
± 1.5dBrdg.±2%f.s
± 4%rdg.±10dgt.
± 1.5dBrdg.±5%f.s.
± 1.5dBrdg.±15%f.s.
± 4%f.s.
± 1.5dBrdg.±5%f.s.
± 1.5dBrdg.±15%f.s.
The value x dBrdg is applied to the stipulated value (dB) under various stan-
dards.
Network
name/filter
status
Accuracy (Deviation from theoretical value. Includes accuracy of internal voltmeter)
Measured current AC, AC+DC ACpeak
range
50 mA, 5 mA,
500
A
50
A 75 mA, 10 mA 1 mA, 500 A
