E1 Series Servo Drive User Manual Basic Function Settings Before Operation
HIWIN MIKROSYSTEM CORP. 6-19
Table6.8.4.4
Parameter Pt508 Range 10~100
Position mode, velocity mode
and torque mode
Default 50 Effective Immediately Unit 10 ms
Description
When servo off and the time set in Pt508 elapses, brake is enabled.
Brake will be enabled when one of the conditions below is satisfied.
a. Power is not supplied to motor and motor velocity is lower than the setting value of Pt507.
Figure6.8.4.1
b. Power is not supplied to motor and the time set in Pt508 elapses.
Figure6.8.4.2
To Next Page
