E1 Series Servo Drive User Manual Appendix
16-12 HIWIN MIKROSYSTEM CORP.
MD09UE01-1910
16.2.3 Connector specification
Table16.2.3.1
Connector
(Cable Side)
HIWIN Part
Number
Description
Main circuit
connector (CN1)
051500400681
AC main power input terminal, control power input terminal, terminal for
regenerative resistor and terminal for DC reactor
D3950/one row 11 Port/7.5 mm/cable side/X key
TE Connectivity 1-2229794-1
Wire size: 22-14 AWG
Suggested: 14 AWG/600 V
Connector for
motor power
cable (CN2)
051500400572
D3950/one row 3 Port/7.5 mm/cable side/X key
TE Connectivity 3-2229794-1
Wire size: 22-14 AWG
Suggested: 14 AWG/600 V
Mini USB
communication
connector (CN3)
051700800366 USB 2.0 Type A to mini-B 5 Pin (1.8 M) (Shielding)
Safety bypass
connector (CN4)
051500400545
INDUSTRIAL MINI I/O BYPASS CONNECTOR TYPE I
TE Connectivity 1971153-1
Safety device
connector (CN4)
051500400404
INDUSTRIAL MINI I/O PLUG CONNECTOR KIT D-SHAPE TYPE 1
TE Connectivity 2013595-1
Connect to external safety device.
Control signal
connector (CN6)
(For standard
servo drive)
051500100141
50 pins, .050” mini D Ribbon (MDR), standard welding-type connector
SCSI 50PIN (male)
Wire size: 24-30 AWG
Control signal
connector (CN6)
(For Fieldbus
servo drive)
051500100213
36 pins, .050” mini D Ribbon (MDR), standard welding-type connector
SCSI 36PIN (male)
Wire size: 24-30 AWG
Encoder
connector (CN7)
180600100002 Shielded compact ribbon (SCR) connectors (363 series)
Connector for
gantry
communication
(CN8)
HIWIN standard communication cable
16.2.4 Accessories for absolute encoder
Table16.2.4.1
Name HIWIN Part Number Description
Lithium battery 051800100013 Voltage: 3.6 VDC
Battery box 051800400029 Battery box for the extension cable of absolute encoder
