E1 Series Servo Drive User Manual Software Settings And Trial Operation
7-4 HIWIN MIKROSYSTEM CORP.
MD09UE01-1910
7.3 Configuration Wizard
Figure7.3.1
Step 6:
Check the parameter settings in each
page of Configuration Wizard by following
the sequence below.
→Preload
→Motor Setup
→Encoder Setup
→Control Mode Setup
→Command Input Setup
→Encoder Output Setup
→I/O Setup
→Send to drive
After that, click on OK button to write
parameters to the servo drive. (Note: If
users would like the parameter settings to
be effective after power off, click on Save
RAM to Flash
button in the main
screen.)
Step 5:
Continue with step 4. Click on the icon of
Setup Window in the upper left corner.
