E1 Series Servo Drive User Manual Software Settings And Trial Operation
HIWIN MIKROSYSTEM CORP. 7-9
MD09UE01-1910
7.6 Trial operation with Thunder
The trial operation described in sections 7.6.1 and 7.6.2 is relatively simple. The purpose of trial operation
is to check the combination of the servo drive and motor as well as the wiring of the servo drive.
7.6.1 JOG
After motion parameters are confirmed, click on Enable button to jog the motor. If an emergency occurs,
press F12 key to immediately stop the motor.
Figure7.6.1.1 JOG
JOG:
Jog+, Jog-
