E1 Series Servo Drive User Manual Tuning
HIWIN MIKROSYSTEM CORP. 10-5
MD09UE01-1910
(4) Linear motor (Analog encoder, pitch: 20 um, analog encoder multiplier factor: 500, encoder
resolution: 20 um/(500 X 4)=0.01 um)
Pt521 >
Motor velocity [ 
⁄
]
102
[
0.1 
⁄ ]
/10
×
1
0.01/1000
×
210
20
×   (: 1.2~2)
When the acceleration or deceleration of position command is too high, the motor may not be able to
follow the position command. At this time, the positon deviation may not satisfy the above formulas.
Decrease the acceleration or deceleration of the position command, or increase the alarm value for
overflow position deviation.
 Related parameter and alarm
Table10.2.3.1
Parameter Pt520 Range 1 ~ 1073741823
Control
Mode
Position mode
Default 5242880 Effective Immediately Unit 1 control unit
Description
Set the alarm value for overflow position deviation (rotary servo motor).
Table10.2.3.2
Parameter Pt521 Range 1 ~ 1073741823
Control
Mode
Position mode
Default 500000 Effective Immediately Unit 1 control unit
Description
Set the alarm value for overflow position deviation (linear servo motor).
Table10.2.3.3
Alarm
Number
Alarm Name Contents
Alarm
Type
Alarm
Reset
AL.d00
Position deviation
overflow
Position deviation exceeds the alarm value for overflow
position deviation (Pt520 or Pt521) when servo ON.
Gr.A Yes
