E1 Series Servo Drive User Manual E1 Series Servo Motor
1-2 HIWIN MIKROSYSTEM CORP.
MD09UE01-1910
Model explanation of servo motor (AC)
The model explanation of E1 series servo motor is provided in table 1.1.1. Refer to the catalogue of EM1
servo motor if detailed motor parameters are needed for evaluation of machine design.
Table1.1.1
Code 1 2 3 4 5 6 7 8 9 10 11 12
Example E M 1 - A L 0 5 2 B E 0 A
1, 2, 3: E1 Series Servo Motor EM1
4: Rated Velocity/Maximum Velocity (rpm)
A = 2000/3000
B = 3000/4500
C = 3000/6000
D = 2000/5000
5: Inertia
L = Low inertia
M = Medium inertia
H = High inertia
6, 7: Rated Power Output
05 = 50 W
10 = 100 W
20 = 200 W
40 = 400 W
75 = 750 W
1K = 1000 W
2K = 2000 W
8: AC Voltage 2 = 220 V
9: Brake
0 = Without brake
B = With brake
10: Serial Encoder
E = 23 bit incremental
F = 23 bit absolute
11: Reserved
0 = Standard
1 = Customized
12: Shaft Type
A = Round shaft/without oil seal
B = Round shaft/with oil seal
C = With key/without oil seal
D = With key/with oil seal
