E1 Series Servo Drive User Manual Basic Function Settings Before Operation
6-8 HIWIN MIKROSYSTEM CORP.
MD09UE01-1910
6.3 Setting main circuit power supply
The main circuit power supply for E1 series servo drive can be single-phase or three-phase. Related
information is provided as below.
6.3.1 Setting single-phase/three-phase AC power input
Users need to specify what power supply is used for the servo drive (single-phase AC 220 V or
three-phase AC 220 V) by setting Pt00B = t.X. An alarm will occur if the input power is different from
the setting.
Table6.3.1.1
Parameter Description Effective Category
Pt00B
t.0
(Default)
Use three-phase AC power input.
After power on Setup
t.1
Use single-phase AC power input or three-phase AC power
input.
For wiring for power supply (CN1), please refer to section 5.3.4.
6.4 Automatic motor identification
E1 series servo drive supports rotary motor (AC servo motor or direct drive motor) and linear motor. The
encoder of the motor must be connected to CN7 connector on the servo drive. If HIWIN serial encoder is
connected, the servo drive will automatically identify the type and related parameters of the connected
motor. And users do not need to set the parameters again.
 If Pt00B is set to t.0 when single-phase AC power is input, AL.F10 (Power
cable open phase) will occur.
 The performance of the motor varies with the input power. Select suitable power
input according to the specification of the motor.
