E1 Series Servo Drive User Manual Basic Function Settings Before Operation
HIWIN MIKROSYSTEM CORP. 6-27
MD09UE01-1910
Example:
The resolution of rotary encoder is 8388608 count/rev. The screw pitch is 10 mm/rev. The reduction
ratio is 1/10. The control unit for each pulse is 1 mm. The calculation is as below.
Electronic gear ratio =
Pt20E
Pt210
=
8388608 count/rev
10(mm/rev) ÷ 1mm
×
10
1
Set Pt20E to 8388608 and Pt210 to 1. Then the load side moves 1 mm when the controller inputs
one pulse.
Linear servo motor
When linear servo motor or full-closed loop control system is used, use electronic gear ratio to
change control unit.
Example 1:
The resolution of linear digital encoder is 0.5 um/count. The control unit for each pulse is 0.1 um. The
calculation is as below.
Electronic gear ratio =
Pt20E
Pt210
=
0.1um
0.5um
Set Pt20E to 1 and Pt210 to 5. When the controller inputs five pulses, the load side moves 0.5 um.
Example 2:
The scale pitch of linear analog encoder is 20 um. The analog encoder multiplier factor is 250. The
encoder resolution is 20 um/(250 x 4)=0.02 um. The control unit for each pulse is 0.1 um. The
calculation is as below.
Electronic gear ratio =
Pt20E
Pt210
=
0.1um
0.02um
Set Pt20E to 50 and Pt210 to 1. When the controller inputs one pulse, the load side moves 0.1 um.
While setting electronic gear ratio, the value of Pt20E/Pt210 needs to be between
0.001 and 64000.
