Hiwin E1 Series User Manual

E1 Series Servo Drive User Manual Application Function
8-86 HIWIN MIKROSYSTEM CORP.
MD09UE01-1910
The screw lead of load side for one revolution is 20 mm. Set Pt20A to 20000 um/rev.
The resolution of external encoder digital optical scale is 5 um. Set Pt20B to 5000 nm.
The reduction ratio is 100:1. It means when the motor side rotates for 100 revolutions, the load side
rotates for one revolution. Set Pt20C to 100 and Pt20D to 1.
 Related parameters
(1) Feed length of external encoder
Table8.16.6.1
Parameter Pt20A Range 1~1000000
Control
Mode
Position mode
Default 20000 Effective After power on Unit 1 um/rev
Description
Set the feed length of external encoder.
(2) Linear unit length of external encoder (resolution)
Table8.16.6.2
Parameter Pt20B Range 1~100000
Control
Mode
Position mode
Default 1000 Effective After power on Unit 1 nm
Description
Set the linear unit length of external encoder (resolution).
Table8.16.6.3
Parameter Pt20C Range 1~65535
Control
Mode
Position mode
Default 1 Effective After power on Unit 1 revolution
Description
Set gear ratio at motor side (full-closed loop).
Table8.16.6.4
Parameter Pt20D Range 1~65535
Control
Mode
Position mode
Default 1 Effective After power on Unit 1 revolution
Description
Set gear ratio at load side (full-closed loop).
