E1 Series Servo Drive User Manual E1 Series Servo Drive
HIWIN MIKROSYSTEM CORP. 2-7
MD09UE01-1910
 The built-in regenerative resistors of E1 series servo drives
Table2.3.1
Model 400 W 1 KW 2 KW
Regenerative
Resistor
Built-in Regenerative
Resistor
Resistance [Ω] N/A 40 12
Capacity [W] N/A 40 60
Minimum Allowable Resistance of External
Regenerative Resistor [Ω]
40 40 12
