E1 Series Servo Drive User Manual Excellent Smart Cube (ESC)
HIWIN MIKROSYSTEM CORP. 3-5
MD09UE01-1910
Table3.3.2.1
Pin
Signal
Description
1 SIN Analog signal input: SIN+
2
COS
Analog signal input: COS+
3
REF
Analog signal input: REF+
4
+5VE
Encoder power output
5
+5VE
Encoder power output
6
N/A
N/A
7
N/A
N/A
8
Hall U
Input for digital Hall sensor: U
9
Hall W
Input for digital Hall sensor: W
10
/SIN
Analog signal input: SIN-
11
/COS
Analog signal input: COS-
12
/REF
Analog signal input: REF-
13
SG
Signal ground
14
SG
Signal ground
15 Inner Shield Inner shield
16
N/A
N/A
17
N/A
N/A
18 Hall V Input for digital Hall sensor: V
19
SG
Signal ground
20
SG
Signal ground
21 SG Signal ground
22
SG
Signal ground
23
SG
Signal ground
24 SG Signal ground
25 TS
Input for thermal sensor: TS+
(HIWIN DM)
26 /TS
Input for thermal sensor: TS-
(HIWIN DM)
Figure3.3.2.2
Comm.
