Hiwin E1 Series User Manual

E1 Series Servo Drive User Manual Parameters
15-2 HIWIN MIKROSYSTEM CORP.
MD09UE01-1910
15.1 Introduction to parameter
The parameter list is described as below.
Pt No.
Pt000
Size 2
Setting
Range
0000~00E1 Default 0010
Name
Basic function
selection 0
Unit -
Applicable
Motor
All
Effective
After power on
Category
Setup
Reference
-
Description
t.X
Rotation/movement direction selection Reference
0
CCW is the forward direction.
-
The direction where the linear encoder counts up is the forward direction.
1
CW direction is the forward direction. (reverse mode)
The direction where the linear encoder counts down is the forward direction.
(reverse mode)
This column indicates the applicable motor for the
parameter.
 All: The parameter can be used with rotary
motor and linear motor.
 Rotary: The parameter can only be used with
rotary motor.
 Linear: The parameter can only be used with
linear motor.
There are two types of
parameters: tuning parameter
and setup parameter.
This column indicates when
the parameter becomes
effective after being modified.
