Hiwin E1 Series User Manual

E1 Series Servo Drive User Manual Parameters
15-24 HIWIN MIKROSYSTEM CORP.
MD09UE01-1910
Pt No.
Pt382
Size 2
Setting
Range
0~10000 Default 30
Name
Internal set velocity
3 (linear servo
motor)
Unit 1 mm/s
Applicable
Motor
Linear
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt383
Size 2
Setting
Range
0~10000 Default 50
Name Jog velocity Unit 1 mm/s
Applicable
Motor
Linear
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt385
Size 2
Setting
Range
0~100 Default 50
Name
Maximum motor
velocity (linear servo
motor)
Unit 100 mm/s
Applicable
Motor
Linear
Effective
After power on
Category
Setup
Reference
-
Pt No.
Pt400
Size 2
Setting
Range
10~100 Default 30
Name
Torque command
input gain
Unit 0.1 V/rated torque
Applicable
Motor
All
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt401
Size 2
Setting
Range
1~65535 Default 100
Name
First stage first
torque command
filter time constant
Unit 0.01 ms
Applicable
Motor
All
Effective
Immediately
Category
Tuning
Reference
-
Pt No.
Pt402
Size 2
Setting
Range
0~800 Default 800
Name Forward torque limit Unit 1%
*1
Applicable
Motor
Rotary
Effective
Immediately
Category
Setup
Reference
-
