E1 Series Servo Drive User Manual Parameters
15-26 HIWIN MIKROSYSTEM CORP.
MD09UE01-1910
Pt No.
Pt408
Size 2
Setting
Range
0000~0101 Default 0000
Name
Torque related
function selection
Unit -
Applicable
Motor
All
Effective
-
Category
Setup
Reference
-
Description
t.X
Notch filter selection 1 Effective Reference
0 Disable first stage notch filter.
Immediately -
1 Enable first stage notch filter.
t.X Reserved (Do not modify.)
t.X Reserved (Do not modify.)
t.X
Notch filter selection 2
Effective
Reference
0 Disable second stage notch filter.
Immediately -
1 Enable second stage notch filter.
Pt No.
Pt409
Size 2
Setting
Range
50~5000 Default 5000
Name
First stage notch
filter frequency
Unit 1 Hz
Applicable
Motor
All
Effective
Immediately
Category
Tuning
Reference
-
Pt No.
Pt40A
Size 2
Setting
Range
50~1000 Default 70
Name
First stage notch
filter Q value
Unit 0.01
Applicable
Motor
All
Effective
Immediately
Category
Tuning
Reference
-
Pt No.
Pt40B
Size 2
Setting
Range
0~1000 Default 0
Name
First stage notch
filter depth
Unit 0.001
Applicable
Motor
All
Effective
Immediately
Category
Tuning
Reference
-
Pt No.
Pt40C
Size 2
Setting
Range
50~5000 Default 5000
Name
Second stage notch
filter frequency
Unit 1 Hz
Applicable
Motor
All
Effective
Immediately
Category
Tuning
Reference
-
