E1 Series Servo Drive User Manual Parameters
15-28 HIWIN MIKROSYSTEM CORP.
MD09UE01-1910
Pt No.
Pt416
Size 2
Setting
Range
0000~0111 Default 0000
Name
Torque related
function selection 2
Unit -
Applicable
Motor
All
Effective
Immediately
Category
Setup
Reference
-
Description
t.X
Notch filter selection 3
0 Disable third stage notch filter.
1 Enable third stage notch filter.
t.X
Notch filter selection 4
0 Disable fourth stage notch filter.
1 Enable fourth stage notch filter.
t.X
Notch filter selection 5
0 Disable fifth stage notch filter.
1 Enable fifth stage notch filter.
t.X Reserved (Do not modify.)
Pt No.
Pt417
Size 2
Setting
Range
50~5000 Default 5000
Name
Third stage notch
filter frequency
Unit 1 Hz
Applicable
Motor
All
Effective
Immediately
Category
Tuning
Reference
-
Pt No.
Pt418
Size 2
Setting
Range
50~1000 Default 70
Name
Third stage notch
filter Q value
Unit 0.01
Applicable
Motor
All
Effective
Immediately
Category
Tuning
Reference
-
Pt No.
Pt419
Size 2
Setting
Range
0~1000 Default 0
Name
Third stage notch
filter depth
Unit 0.001
Applicable
Motor
All
Effective
Immediately
Category
Tuning
Reference
-
