E1 Series Servo Drive User Manual Parameters
15-46 HIWIN MIKROSYSTEM CORP.
MD09UE01-1910
Pt No.
Pt550
Size 2
Setting
Range
-10000~10000 Default 0
Name
Analog monitor 1
offset voltage
Unit 0.01 V
Applicable
Motor
All
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt551
Size 2
Setting
Range
-10000~10000 Default 0
Name
Analog monitor 2
offset voltage
Unit 0.01 V
Applicable
Motor
All
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt552
Size 2
Setting
Range
-10000~10000 Default 100
Name
Analog monitor 1
scale
Unit x 0.01
Applicable
Motor
All
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt553
Size 2
Setting
Range
-10000~10000 Default 100
Name
Analog monitor 2
scale
Unit x 0.01
Applicable
Motor
All
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt580
Size 2
Setting
Range
0~10000 Default 10
Name
Zero clamp level
(linear servo motor)
Unit 1 mm/s
Applicable
Motor
Linear
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt581
Size 2
Setting
Range
1~10000 Default 20
Name
Movement detection
value (linear servo
motor)
Unit 1 mm/s
Applicable
Motor
Linear
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt582
Size 2
Setting
Range
0~100 Default 10
Name
Output range of
velocity reach signal
(linear servo motor)
Unit 1 mm/s
Applicable
Motor
Linear
Effective
Immediately
Category
Setup
Reference
-
