Hiwin E1 Series User Manual

E1 Series Servo Drive User Manual Parameters
15-50 HIWIN MIKROSYSTEM CORP.
MD09UE01-1910
Pt No.
Pt710
Size 2
Setting
Range
0000~0001 Default 0000
Name
Gantry control
system home
application selection
Unit -
Applicable
Motor
All
Effective
After power on
Category
Setup
Reference
-
Description
t.X
Locking function for yaw axis in gantry control system
0 Disable yaw axis locking function for gantry control system.
1 Enable yaw axis locking function for gantry control system.
t.X Reserved (Do not modify.)
t.X Reserved (Do not modify.)
t.X Reserved (Do not modify.)
Pt No.
Pt711
Size 4
Setting
Range
-1073741824 ～
1073741824
Default 0
Name
Home offset of yaw
axis in gantry control
system
Unit 1 control unit
Applicable
Motor
All
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt712
Size 4
Setting
Range
-1073741824 ～
1073741824
Default 0
Name
Locking position of
yaw axis in gantry
control system
Unit 1 control unit
Applicable
Motor
All
Effective
Immediately
Category
Setup
Reference
-
Note:
(1) *1. The percentage of rated torque
(2) *2. While using direct drive motor, the default values of Pt304 and Pt533 are set to 60 rpm.
(3) *3. The setting value of this parameter is normally 0. When external regenerative resistor is used, the
parameter should be set to the capacity (W) of the external regenerative resistor.
(4) *4. The upper limit value is the maximum output power (W) of the servo drive.
