E1 Series Servo Drive User Manual Appendix
HIWIN MIKROSYSTEM CORP. 16-7
MD09UE01-1910
□ stands for cable length, please refer to below.
Table16.1.4.2
□ 3 5 7 A
Cable Length
(m)
3 5 7 10
Table16.1.4.3
Name HIWIN Part Number Description
ESC encoder
communication
cable
HE00EJUDA□00 For connecting ESC to CN7 on the servo drive
□ stands for cable length, please refer to below.
Table16.1.4.4
□ 1 2 3
Cable Length
(m)
1 2 3
Note:
For other cable lengths, please contact local distributor.
Table16.1.4.5 ESC temperature cable
Name HIWIN Part Number Description
ESC temperature
cable
HE00EKDDA□00
For extending thermal wires
This cable may be required if the distance between ESC and
the servo drive is over 0.5 m.
□ stands for cable length, please refer to below.
Table16.1.4.6
□ 1 2 3
Cable Length
(m)
1 2 3
Note:
For other cable lengths, please contact local distributor.
