INSTRUMENT TROUBLESHOOTING

6.36

ThinPrep 2000 Processor Operator’s Manual

Stop Key Pressed

Reason for Message

This message appears when the user presses the STOP key during a sequence. The instrument will

automatically abort the sequence and perform error recovery.

Possible Causes

• STOP key pressed during a sequence
