INTRODUCTION

1.18

ThinPrep 2000 Processor Operator’s Manual

Location of Labels Used on the Instrument

Figure 1-7 Location of Labels Used on the Instrument

Do not dispose symbolSlide insertion label Serial number label

Model/rating label

Moving parts

label

Flammable liquids

label
