Hologic thinprep 2000 - Removing the Rotating Plate Packaging

To Next Page

To Previous Page

THINPREP 2000 INSTALLATION

2.4

ThinPrep 2000 Processor Operator’s Manual

Figure 2-1 Removing the Rotating Plate Packaging

3. The rotating plate can be turned clockwise into a horizontal position.

Foam shipping insert

Rotating plate

Grasp and pull the foam

insert straight forward, out of

the instrument
