OPERATING INSTRUCTIONS
ThinPrep 2000 Processor Operator’s Manual
5A.13
5. To fully insert the slide, place your index fingers against the exposed edge of the slide and push
the slide in until it does not go any further, as shown in Figure 5A-10. The slide handler clamps
grasp the slide when the slide is seated correctly and the slide moves up slightly behind the
upper guide block.
Figure 5A-10 Inserting the Slide Fully
Note:
To remove a slide, press down on the front edge of the slide. Gently pull the slide toward you.
LABEL
EN
D
