INTRODUCTION

1.12

ThinPrep 2000 Processor Operator’s Manual

THINPREP 2000 SYSTEM TECHNICAL SPECIFICATIONS

Overview of Components

Figure 1-4 ThinPrep 2000 System Components

SECTION

ThinPrep 2000

Fix vials

Power cord

Program Memory

Card

Operator’s manual Filter cap assemblies

Waste bottle with cap

and filter
