INTRODUCTION

ThinPrep 2000 Processor Operator’s Manual

1.13

ThinPrep 2000 Dimensions and Clearances

Figure 1-5 Processor Dimensions

Figure 1-6 Processor Clearances

19.5”/50 cm

15”/38 cm

17”/43 cm

18”/46 cm

6”/15 cm

22.5/59 cm

18/46 cm

24/61 cm
