Level 1
main
menu ID
number
Level 1 main
menu categories
Level 1 main
menu as
displayed on LCD
Level 1 submenu
as displayed on
LCD
Item
code
Description
L1.2 Alarm
Information
ALARMS
Displays
individual
alarms. Press OK,
the active alarms
appear on the
display.
The individual
alarm items are
not displayed in
the L1.2 menu,
unless that
particular alarm
is active.
BAT LO ALM 99 Battery Voltage
Lo Alarm
BAT WC ALM 100 Battery
Consumption Hi
Alarm
SW-1 ALARM 102 Input Vol Switch-
1 Fault Alarm
SW-2 ALARM 103 Input Vol Switch-
1 Fault Alarm
SYS ALARM 104 System Error
Alarm
P LO ALARM 143 Gas Pressure Lo
Alarm
P HI ALARM 144 Gas Pressure Hi
Alarm
T LO ALARM 145 Gas Temperature
Lo Alarm
T HI ALARM 146 Gas Temperature
Hi Alarm
FLOW HI ALM 163 Flow Rate Hi
Alarm
To Next Page
