Honeywell EC350 - 4.3.3 Sending a user table file

l
Click Apply to save the privileges for the newly created user.
l
Click Save.
The Save User Table File As dialog box appears.
l
Enter a filename and click OK.
The Choose Password dialog box appears.
l
Enter a password and click OK. This password is required when you want to send the user table file.
4.3.3 Sending a user table file
To send a user table file:
l
Establish a serial communication between EC350 and MasterLink Software Application SQL. Refer
to the MasterLink Software Application SQL User’s Guide for information about establishing a serial
connection between EC350 and MasterLink Software Application SQL.
l
In the MasterLink Software Application SQL window, click Transfer > Send User Table.
4 Securing the device
4.3 Defining access privileges
