6.2.5 Entering the site ID
l
Unlock the keypad and type the PASSCODE to enter level 2 mode or level 3 mode. Refer to the
section “ Accessing level 2 mode ” for accessing level 2 mode or section “ Access level 3 mode ” for
accessing level 3 mode.
l
By default, in level 2 mode or level 3 mode the following appears on the display.
MAIN MENU
ALARMS
l
Using the UP arrow and DOWN arrow scroll through the options in level 2 mode or level 3 mode
until CONFIG appears.
l
Press OK. The following appears on the display.
CONFIG
ALARMS
l
Using the UP arrow and DOWN arrow scroll through the options in level 2 mode or level 3 mode
until INSTRUMENT appears.
l
Press OK.
The following appears on the display.
INSTRUMENT
SITE INFO
l
Press OK, the following appears on the display.
UNIT S/N
l
Using the UP arrow and DOWN arrow scroll through the options until SITE ID #1 appears.
l
To change the SITE ID #1, press OK and then using the keypad enter the eight-digit SITE ID.
l
SITE ID is in addition to the UNIT S/N. Follow the site-specific rules for configuring the site ID
number.
l
Once you enter all the eight digits, press OK.
