5.4 Alarms
EC350 monitors a list of parameters and compares their measured values to configurable limits to
determine if a fault condition has occurred. When any of these measured parameters has exceeded their
respective limit, EC350 will create an Alarm.
EC350 currently supports monitoring eight (8) parameters and supplies an Alarm Item for each. Shown
below are the eight Alarm Items.
Alarm Item Alarm
Item No.
Alarm Limit
Item
Alarm
Limit Item
No.
Basic Operational Description
Battery Low 99 Battery Low
Limit
49 Battery life remaining < set limit
Battery Cycles
Alarm
100 Battery Months
Remaining
1001 Battery life months remaining < set limit
Volume Sensor
1
102 n/a n/a Internal tests
Volume Sensor
2
103 n/a n/a Internal tests
System Alarm 104 n/a n/a Internal tests
Pressure Low 143 Pressure low
limit
11 Gas pressure < set low limit
Pressure High 145 Pressure high
limit
10 Gas pressure > set high limit
Temperature
Low
144 Temperature
low limit
027 Gas temperature < set low limit
Temperature
High
146 Temperature
high limit
028 Gas temperature > set high limit
Flow Rate high 163 Flow rate high
limit
164 Flow rate > set high limit
Daily Cor
volume
222 Daily cor
volume limit
221 Daily CorVol > set limit
P2 Press High
Alarm
451 P2 Press High
Alarm Limit
455 Alarm is raised when P2 goes above its
high limit
P2 Press Low
Alarm
452 P2 Press Low
Alarm Limit
456 Alarm is raised when P2 goes below its
low limit
Extern Supply
Low Alarm
796 External
Supply Low
Limit
795 Alarm is raised when external supply
voltage goes below its low limit
5 Key features
5.4 Alarms
Honeywell 2024
87
