8.8 User Shelf/ Shutdown mode
The EC350 can be placed in to a User Shelf / Shutdown mode to take it out of service for extended periods
of time. This mode is useful to conserve battery life when the instrument is not in use. In this mode EC350
conserves battery energy by limiting most of its normal functionality while preserving data and keeping
time.
You can enter user shutdown mode using:
l
HMI menu levels 2 or 3
l
MasterLink Software Application SQL
l
To enter user shutdown mode using HMI mode 2 or 3
l
To enter user shutdown mode using MasterLink Software Application SQL
8.8.1 To enter user shutdown mode using HMI mode 2 or 3
l
Unlock the keypad and type the PASSCODE to enter level 2 mode or level 3 mode Refer to the
section “Accessing level 2 mode” for accessing level 2 mode or section “Access level 3 mode” for
accessing level 3 mode.
l
By default, the following appears on the display.
MAIN MENU
ALARMS
l
Using the UP arrow and DOWN arrow scroll through the options in level 2 mode or level 3 mode
until SHUTDOWN appears.
l
Press OK. The following appears on the display.
ENTER MODE
l
Press OK to confirm.
EC350 enters shutdown/shelf mode.
l
Press ESC to exit HMI mode 2 or 3.
8.8.2 To enter user shutdown mode using MasterLink Software Application SQL
l
Establish a serial communication between EC350 and MasterLink Software Application SQL. Refer
to the MasterLink Software Application SQL User’s Guide for information about establishing a serial
connection between EC350 and MasterLink Software Application SQL.
l
In the MasterLink Software Application SQL window, click Instrument > Shutdown.
l
Click Yes.
8 Maintenance
8.8 User Shelf/ Shutdown mode
