5.3.4 Volume per proving output pulse
In Pushbutton Proving mode, EC350 writes electronic switch closure pulses to the prover system with a
predefined volume scaling factor of: one (1), ten (10), or one hundred (100) cubic feet (CF) of gas volume,
depending upon the rotary meter model Rotary integral mount (item 432) . The following table represents
the predefined volume scaling factor for the rotary meter models.
Output Pulse Amount
1.0 CF 10.0 CF 100.0 CF
Dresser B3 Meters
B3 8C175 200 B3 23M175
B3 11C175 200 B3 23M232
B3 15C175 200 B3 38M175
B3 1M300 B3 56M175
B3 2M175 200
B3 3M175 300
B3 5M175
B3 7M175
B3 11M175
B3 16M175
Dresser LMMA Meters
LMMA 1.5M LMMA 23M LMMA 102M
LMMA 2M LMMA 38M
LMMA 3M LMMA 56M
LMMA 5M
LMMA 7M
LMMA 11M
LMMA 16M
