Honeywell EC350 User Manual

6 User Access
6.2 Working with HMI
Honeywell 2024
157
6.2.7.2 Selecting the unit of measurement for energy
To select the unit of measurement for energy:
l
Unlock the keypad and type the PASSCODE to enter level 2 mode or level 3 mode. Refer to the
section “ Level 2 mode ” for accessing level 2 mode or section “ Level 3 mode ” for accessing level 3
mode.
l
By default, in level 2 mode or level 3 mode the following appears on the display.
MAIN MENU
ALARMS
l
Using the UP arrow and DOWN arrow scroll through the options in level 2 mode or level 3 mode
until CONFIG appears.
l
Press OK. The following appears on the display.
CONFIG
ALARMS
l
Using the UP arrow and DOWN arrow scroll through the options in level 2 mode or level 3 mode
until ENERGY appears.
l
Press OK.
By default, the following appears on the display.
00000000
THERMS
ENERGY
l
Press the DOWN arrow key.
The following appears on the display.
THERMS
ENERGY UNIT
l
Press OK and then using the UP arrow and DOWN arrow increase or decrease the value of Code.
The corresponding unit associated with the code appears. For example, Code 0 represents
THERMS .
Following are the codes and the corresponding units of measurement for ENERGY.
