6 User Access
6.2 Working with HMI
Honeywell 2024
149
6.2.4 Testing the pulse input
To test the pulse input:
l
Unlock the keypad and type the PASSCODE to enter level 2 mode or level 3 mode. Refer to the
section “ Accessing level 2 mode ” for accessing level 2 mode or section “ Access level 3 mode ” for
accessing level 3 mode.
l
By default, in level 2 mode or level 3 mode the following appears on the display.
MAIN MENU
ALARMS
l
Using the UP arrow and DOWN arrow scroll through the options in level 2 mode or level 3 mode
until DIAGNOSTIC appears.
l
Press OK.
By default, the following appears on the display.
DIAGNOSTIC SENSOR TST
l
Press OK. The following appears on the display.
0 0
ERR CNTS
SENSOR TST
Ensure that the value of ERR remains zero +/- one count, whereas the value of CNTS must increase with
each volume input.
