3 EC350 installation
This chapter deals with the installation of EC350 on conventional gas meters (such as
rotary, diaphragm, and turbine). This chapter also provides procedures for installing and
replacing the battery and output wire connections to obtain pulse output from EC350.
l
EC350 contents verification
l
Overview of installation
l
Model number interpretation
l
Prerequisites
l
Installing EC350 on conventional diaphragm, rotary or turbine gas meters
l
Installing EC350 on a rotary mount
l
Power Supply Options
l
General Wiring connections
l
Installation Drawings
