Honeywell EC350 User Manual

6 User Access
6.2 Working with HMI
Honeywell 2024
143
6.2 Working with HMI
Choosing the meter type
l
Choosing the meter type
l
Verifying pressure
l
Verifying temperature
l
Testing the pulse input
l
Entering the site ID
l
Setting the date and time
l
Selecting the unit of measure
l
Single point temperature and pressure calibration
6.2.1 Choosing the meter type
l
Unlock the keypad and type the PASSCODE to enter level 2 mode or level 3 mode. Refer to the
section “ Accessing level 2 mode ” for accessing level 2 mode or section “ Access level 3 mode ” for
accessing level 3 mode.
l
By default, in level 2 mode or level 3 mode the following appears on the display.
MAIN MENU
ALARMS
Using the UP arrow and DOWN arrow scroll through the options in level 2 mode or level 3 mode
until CONFIG appears.
l
Press OK. The following appears on the display.
CONFIG
ALARMS
l
Using the UP arrow and DOWN arrow scroll through the options until METER TYPE appears.
l
Press OK.
The following default meter maker appears on the display.
METER TYPE
DRESSER
The following preconfigured types of makers of meters appear. Using the UP arrow and DOWN
arrow scroll through the options.
