6 User Access
6.2 Working with HMI
Honeywell 2024
147
6.2.3 Verifying temperature
To verify the temperature:
l
Unlock the keypad and type the PASSCODE to enter level 2 mode or level 3 mode. Refer to the
section “ Accessing level 2 mode ” for accessing level 2 mode or section “ Access level 3 mode ” for
accessing level 3 mode.
l
By default, the following appears on the display.
MAIN MENU
ALARMS
l
Using the UP arrow and DOWN arrow scroll through the options in level 2 mode or level 3 mode
until VERITY P/T appears.
l
Press OK. The following appears on the display.
VERIFY P/T
VALIDATE P
l
Press the DOWN arrow, the following appears on the display.
VERIFY P/T
VALIDATE T
l
Press OK, the temperature read by EC350 appears on the display.
For example:
75.20
F
LIVE TEMP
Here, 75.20 is the value that EC350 reads and F stands for the unit of temperature that is
Fahrenheit.
l
Press OK. The following appears on the display.
75.20
F
INPUT REFT
Here, REFT stands for reference temperature.
l
Enter the reference temperature (the temperature that EC350 must read) by using the keypad and
then press
OK.
