CCF
CV UNITS
l
Press OK and then using the UP arrow and DOWN arrow increase or decrease the value of
Code.
The corresponding unit associated with the code appears. For example, Code 0 represents CF.
Following are the codes and the corresponding units of measurement for VOLUME.
Code Units
Code 0 CF
Code 1 CFX10
Code 2 CFX100
Code 3 CFX1K
Code 4 CFX10K
Code 5 CCF
Code 6 MCF
Code 7 M3X0.1
Code 8 M3
Code 9 M3X10
Code 10 M3X100
Code 11 M3X1K
l
Press OK to select the required unit.
For example, if you press OK at Code 0, CF is selected as the unit of corrected volume.
l
Repeat step 6 through step 10 for selecting the unit for uncorrected volume. Selecting the unit of
measurement for energy
6 User Access
6.2 îWorking with HMI
