6 User Access
6.1 Getting started with the keypad
Honeywell 2024
113
Level 1
main
menu ID
number
Level 1 main
menu categories
Level 1 main
menu as
displayed on LCD
Level 1 submenu
as displayed on
LCD
Item
code
Description
L1.7 Pressure
Information
PRESSURE Displays the
pressure
information.
Press OK, the
following items
appear on the
display.
GAS PRESS 008 Gas Pressure
P RNG PSI 025 Press Transducer
Range (psi)
XDUCER TYP 112 Press Transducer
Type
PRESS UNIT 087 Pressure Units
P-XDCR S/N 138 Press Transducer
Serial No.
PRESS FACT 044 Pressure Factor
P-FAC CALC 109 Press Factor
Calculation Type
BASE PRESS 013 Base Pressure
AMT PRESS 014 Atmospheric
Pressure
