Monitoring and Operating the Controller
132 UDC2500 Universal Digital Controller Product Manual 4/07
Close the IR configuration window and then single click on the Online Configuration
button shown in Figure 4-12.
Figure 4-12 Online Configuration
Press any button on the controller’s keyboard to activate the controller’s IR port. Point
your IR dongle (if using PC) or your Pocket PC’s IR port (if using Pocket PC) at the IR
window on the front of the controller and then click on the Start button. The P.I.E. Tool
®
should start uploading the configuration information from the controller as shown below:
Figure 4-13 Configuration Upload in Progress
Once the upload is complete, click on the Ethernet & Email Group. Configure your
Ethernet and Email parameters per Section
3.16.
Once you have changed the Ethernet settings and downloaded them to your controller,
you will now be able to communicate with it via Ethernet.
