Honeywell UDC2500 User Manual

Modbus Read, Write and Override Parameters plus Exception Codes
4/07 UDC2500 Universal Digital Controller Product Manual 209
10.7.8 Control
Table 10-16 lists all the register addresses and ranges or selections for the function
prompts in Set-up Group Control.
Table 10-16 Set-up Group – Control
Parameter
Description
Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Hex Decimal
Tuning
Parameter
Selection
00AC 172 INT R/W 0 = One set only
1 = 2 sets keyboard selected
2 = 2 sets with PV automatic
switchover
3 = 2 sets with setpoint (SP)
automatic switchover
Automatic
Switchover
Value (used with
172 selection 2
or 3)
0038 056 FP R/W Within the PV Range in
engineering units
Local Setpoint
Source (Number
of LSPs)
00AD 173 INT R/W 0 = One Local Setpoint
1 = Two Local Setpoints
Power Up Mode
Recall
0082 130 INT R/W
Control Setpoint
Mode Mode
0 = MAN LSP
1 = AUTO LSP
2 = AUTO Last RSP
3 = LAST Last SP
4 = LAST Last Local SP
RSP Source 0083 131 INT R/W 0 = None
1 = Input 2
Setpoint
Tracking
008A 138 INT R/W 0 = None
1 = LSP = PV (when in
Manual)
2 = LSP = RSP (when
switched)
Control Setpoint
High Limit
0007 007 FP R/W 0 to 100% of PV
(engineering units)
Control Setpoint
Low Limit
0008 008 FP R/W 0 to 100% of PV
(engineering units)
Control Output
Direction
0087 135 INT R/W 0 = Direct
1 = Reverse

Honeywell UDC2500 Specifications

General

Type	Universal Digital Controller
Alarm Relays	Up to 2 alarm relays
Communication	RS485 Modbus RTU
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, V
Control Modes	On/Off, PID
Output Types	Relay, mA, V
Power Supply	100-240 VAC, 24V DC
Dimensions	96x96x132 mm
