Configuration
82 UDC2500 Universal Digital Controller Product Manual 4/07
3.15 Display Set Up Group
Introduction
This group includes selections for Decimal place, Units of temperature, Language and
Power frequency.
Function Prompts
Table 3-16 DISPLY Group (Numeric Code 1200) Function Prompts
Function Prompt
Lower Display
Selection or Range of Setting
Upper Display
English Numeric
Code
English Numeric
Code
Parameter
Definition
DECMAL 1201
NONE
ONE
TWO
DECIMAL POINT LOCATION—This
selection determines where the decimal point
appears in the display.
NONE—No Decimal Place—fixed, no auto-
ranging 8888
ONE—1 decimal place 888.8
TWO—2 decimal places 88.88
ATTENTION Auto-ranging will occur for
selections of one or two decimal places. For
example, should the instrument be
configured for two decimal places and the
PV exceeds 99.99, then the display will
change to a single decimal place so that
values of 100.0 and above can be shown.
UNITS 1202
TEMPERATURE UNITS—This selection will
affect the indication and operation.
F 0
DEG F—Degrees Fahrenheit – Degrees F
Annunciator lighted
C 1
DEG C—Degrees Centigrade – Degrees C
Annunciator lighted
NONE 2
NONE—No temperature annunciators
lighted. Upper and Lower Displays will show
temperature in Degrees Fahrenheit when
inputs are configured for Thermocouple or
RTD types.
