Configuration
34 UDC2500 Universal Digital Controller Product Manual 4/07
3.3 Configuration Procedure
Introduction
Each of the Set Up groups and their functions are pre-configured at the factory.
The factory settings are shown in
Table 3-4 through Table 3-15 that follow this
procedure.
If you want to change any of these selections or values, follow the procedure in
Table
3-3. This procedure tells you the keys to press to get to any Set Up group and any
associated Function parameter prompt.
Procedure
ATTENTION
The prompting scrolls at a rate of 2/3 seconds when the SET UP or FUNCTION key is held in.
Also,
or keys will move group prompts forward or backward at a rate twice as fast.
Table 3-3 Configuration Procedure
Step Operation Press Result
1
Enter Set Up
Mode
SetupSetup
Upper Display = SET
Lower Display = TUNING (This is the first Set Up Group
title)
2
Select any Set
Up Group
SetupSetup
Sequentially displays the other Set Up group titles shown in
the prompt hierarchy in
Table 3-2 Configuration Prompt
Hierarchy.
You can also use the
or keys to scan the Set Up
groups in both directions. Stop at the Set Up group title that
describes the group of parameters you want to configure.
Then proceed to the next step.
3
Select a Function
Parameter
FunctionFunctionFunction
Upper Display = the current value or selection for the first
function prompt of the selected Set Up
group.
Lower Display = the first Function prompt within that Set Up
group.
Sequentially displays the other function prompts of the Set
Up group you have selected. Stop at the function prompt
that you want to change, then proceed to the next step.
4
Change the
Value or
Selection
or
Increments or decrements the value or selection that
appears for the selected function prompt. If you change the
value or selection of a parameter while in Set Up mode then
decide not to enter it, press M-A RESET once—the original
value or selection is recalled.
5
Enter the Value
or Selection
FunctionFunctionFunction
Enters value or selection made into memory after another
key is pressed.
6
Exit Configuration
Lower
Display
Lower
Display
Lower
Display
Exits configuration mode and returns controller to the same
state it was in immediately preceding entry into the Set Up
mode. It stores any changes you have made.
If you do not press any keys for 30 seconds, the controller
times out and reverts to the mode and display used prior to
entry into Set Up mode.
