Modbus Read, Write and Override Parameters plus Exception Codes

4/07 UDC2500 Universal Digital Controller Product Manual 207

10.7.7 Input 2

Table 10-15 lists all the register addresses and ranges or selections for the function

parameters in Set-up Group Input 2.

Table 10-15 Set-up Group – Input 2

Parameter

Description

Address

Data

Type

Access Data Range or

Enumerated Selection

Hex Decimal

Input 2 Type 00AA 170 INT R/W

0 = Disable

1 to 25 Unused

26 = 0-20 mA

27 = 4-20 mA

28 to 30 = Unused

31 = 0-5 Vdc

32 = 1-5 Vdc

33 = Unused

34 = Unused

35 = 0 – 2 Vdc

ATTENTION

Changing the Input Type will result in the loss of Field Calibration

values and will restore the Factory Calibration values.
