Configuration
38 UDC2500 Universal Digital Controller Product Manual 4/07
Function Prompt
Lower Display
Selection or Range of Setting
Upper Display
English Numeric
Code
English Numeric
Code
Parameter
Definition
read/write.
CAL 1
CALIBRATION—All groups are available for
read/write except for the Calibration and
Keyboard Lockout groups.
CONF 2
+ CONFIGURATION—Tuning, SP Ramp,
and Accutune groups are read/write. All
other groups are read only. Calibration and
Keyboard Lockout groups are not available.
VIEW 3
+ VIEW—Tuning and Setpoint Ramp
parameters are read/write. No other
parameters are viewable.
ALL 4
ALL—Tuning and Setpoint Ramp
parameters are available for read only. No
other parameters are viewable.
AUTOMA 112
DIS
ENAB
0
1
MANUAL/AUTO KEY LOCKOUT—Allows
you to disable the Manual/Auto key.
DISABLE
ENABLE
ATTENTION Can only be viewed if
LOCKOUT is configured for NONE.
RN HLD 114
DIS
ENAB
0
1
RUN/HOLD KEY LOCKOUT—Allows you to
disable the Run/Hold key, for either SP
Ramp or SP Program. The Run/Hold key is
never disabled when used to acknowledge a
latched alarm 1 or a Diagnostic Message.
DISABLE
ENABLE
ATTENTION Can only be viewed if
LOCKOUT is configured for NONE.
SP SEL 115
DIS
ENAB
0
1
SETPOINT SELECT KEY LOCKOUT—
Allows you to disable the Setpoint Select
key.
DISABLE
ENABLE
ATTENTION Can only be viewed if
LOCKOUT is configured for NONE.

Honeywell UDC2500 Specifications

General

Type	Universal Digital Controller
Alarm Relays	Up to 2 alarm relays
Communication	RS485 Modbus RTU
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, V
Control Modes	On/Off, PID
Output Types	Relay, mA, V
Power Supply	100-240 VAC, 24V DC
Dimensions	96x96x132 mm
