Configuration
4/07 UDC2500 Universal Digital Controller Product Manual 41
Function Prompt
Lower Display
Selection or Range of Setting
Upper Display
English Numeri
c Code
English Numeric
Code
Parameter
Definition
EUHRDN 206
0 to 9999 in
Engineering units
per hour
RATE DOWN—Rate down value. When
making a setpoint change, this is the rate at
which the controller will change from the
original setpoint down to the new one. The
ramping (current) setpoint can be viewed as
SPn in the lower display.
Entering a 0 will imply an immediate change
in Setpoint (i.e., no rate applies).
SPPROG
(optional
feature)
SP Ramp
must be
disabled for
SP Program
prompts to
appear. If
SP Rate is
enabled, it
does not
operate
while an SP
Program is
running.
207
DIS
ENAB
0
1
SETPOINT RAMP/SOAK PROGRAM—
Available only with controllers that contain
this option.
SP RAMP must be disabled.
DISABLE—Disables setpoint programming.
ENABLE—Enables setpoint programming.
ATTENTION Detailed information for the
prompts for SP Programming may be found
in Section
4.21 – Setpoint Programming. The
listing below is only for reference purposes.
STRSEG 208
1 to 11 Start Segment Number
ENDSEG 209
2 to 12 (always end in
a soak segment)
SOK 2
SOK 4
SOK 6
SOK 8
SOK 10
SOK 12
2
4
6
8
10
12
End Segment Number
RPUNIT 210
TIME
EU-M
EU-H
0
1
2
Engineering Units for Ramp Segments
TIME in hours:minutes
RATE in Enineering units per minute
RATE in Enineering units per hour
RECYCL 211 0 to 100 recycles
Number of Program Recycles
SOKDEV 212 0 to 100
Guaranteed Soak Deviation Value
PG END 213 LAST (Hold at last
SP) FSAF (Manual
mode/failsafe)
0
1
Program Termination State
