Configuration
50 UDC2500 Universal Digital Controller Product Manual 4/07
Function Prompt
Lower Display
Selection or Range of Setting
Upper Display
English Numeric
Code
English Numeric
Code
Parameter
Definition
L DISP 405
TREM
ET
0
1
L DISP allows you to select whether time
remaining (TI REM) or elapsed time (E
TIME) is displayed for the timer option.
The time is shown on the lower display in
HH:MM format along with a rotating “clock”
character.
• If the “clock” rotation is clockwise, elapsed
time is indicated.
• If the “clock” rotation is counterclockwise,
time remaining is indicated.
RESET 406
Key
AL1
0
1
RESET TIMER determines how the Timer
will be set back to zero.
KEY – Reset Timer via Run/Hold Key
ALARM 1 – Reset the Timer via either Alarm
1 or Run/Hold Key
INCRMT 407
MIN
SEC
0
1
INCREMENT This selection determines how
the timer’s count will increment.
MINUTES Counts are in Hours/Minutes
SEC Counts are in Minutes/Seconds
