IPv4 Access Control Lists (ACLs)

Planning an ACL Application

Caution IPv4 ACLs can enhance network security by blocking selected traffic, and can

serve as one aspect of maintaining network security. However, because ACLs

do not provide user or device authentication, or protection from malicious

manipulation of data carried in IP packet transmissions, they should not

be relied upon for a complete security solution.

Note Static ACLs for the switches covered by this guide do not filter non-IPv4 traffic

such as IPv6, AppleTalk, and IPX. Dynamic port ACLs assigned by a RADIUS

server can be configured on the server to filter IPv4 traffic, but do not filter

non-IP traffic.

Guidelines for Planning the Structure of a Static ACL

After determining the filtering type (standard or extended) to use at a partic-

ular point in your network, determine the order in which to apply individual

ACEs to filter IPv4 traffic (For information on ACL applications, refer to “ACL

Applications” on page 9-14.).

■ The sequence of ACEs is significant. When the switch uses an ACL to

determine whether to permit or deny an ip packet, it compares the

packet to the criteria specified in the individual Access Control

Entries (ACEs) in the ACL, beginning with the first ACE in the list and

proceeding sequentially until a match is found. When a match is

found, the switch applies the indicated action (permit or deny) to the

packet.

■ The first match in an ACL dictates the action on a packet. Subsequent

matches in the same ACL are ignored. However, if a packet is

permitted by one ACL assigned to an interface, but denied by another

ACL assigned to the same interface, the packet will be denied on the

interface.

■ On any ACL, the switch implicitly denies IPv4 packets that are not

explicitly permitted or denied by the ACEs configured in the ACL. If

you want the switch to forward a packet for which there is not a match

in an ACL, append an ACE that enables Permit Any forwarding as the

last ACE in the ACL. This ensures that no packets reach the Implicit

Deny case for that ACL.

9-26
